| Technical Data |
| Transmitter Frequency |
X-band, 9.4GHz |
| Radar Waveform |
FMCW |
| LFM Sweep Bandwidth |
≦160MHz |
| Range Performance |
350m for Human
800m for Light Vehicle |
| Radar Range Modes |
125m/250m/500m/1000m/2000m |
| Range Resolution |
1m |
| AZ Beamwidth |
5.8° |
| AZ Coverage |
360° |
| Rotation Rate |
24/36/48/60 RPM ; Selectable |
| Transmitter Source (warm-up time) |
No magnetron - All solid state.
No Warm-Up Time |
| Transmitter Peak Power |
20dBm |
| PRF |
175Hz ~ 476 Hz Programmable |
| MTI Types |
No MTI, One or Two Delay MTI |
| Power Consumption |
Operating: 25W (Typ.) @ 12 vDC |
| DC Input |
9 to 31.2 VDC (12/24 Volt systems) |
| Outside Dimensions |
293*Φ511 |
| Comm Protocol |
High-Speed Ethernet (100 Base-T) |
